Yokogawa WT2010, Digital Power Meter, W/ Options: -C1-7-F, B5, HRM & FL

Unit is tested and in good both working and cosmetic condition. Please see pictures!


Condition: Tested good

Options: C1-7-F, B5, HRM and FL
Serial number: 2531HA006 B

Need calibration for the unit? Please contact us and we'll send you a affordable calibration quote!

Generic description (Took from manufacturer’s webpage)

Note. Description only dependent on installed options. Please see unit pictures for options!

The WT2010/2030 (hereinafter referred to as the WT2000 series) are based on the conventional highest-grade 2531 power meter, though they have improved fundamental accuracy (from 0.1% to 0.08% for power measurement) and bandwidth (from 300 kHz to 500 kHz for voltage/current measurement). In addition, the maximum number of analyzable orders of harmonics has been made variable from 1 to 50 and the harmonics window for analysis has been made selectable. A major improvement has also been made to the transmission rate, enabling output of 36 data items at a maximum speed of 250 ms.

Features

(1) High Accuracy

  • Fundamental accuracy:
    0.04% of reading + 0.04% of range (50/60 Hz, power measurement)
    0.03% of reading + 0.03% of range (50/60 Hz, voltage/ current measurement)

  • Bandwidth: DC, 2 Hz to 500 kHz

  • Error in power factor: 0.1% of range (50/60 Hz, power factor = 0)

  • Measuring ranges:
    Voltage: 10, 15, 30, 60, 100, 150, 300 or 600 V
    Current: Direct input: 1, 2, 5, 10, 20 or 30 A; external shunt input: 50, 100 or 200 mV

  • Functions:
    Current-and power-based integration (with capability of polarity-based integration)
    Harmonics analysis function complying with IEC1000-3-2 (optional); voltage fluctuations/flicker measurement function complying with IEC1000-3-3 (optional); built-in printer; manual/automatic printing (optional); 14-channel D/A output (optional)

(2) Voltage Fluctuations/Flicker Measurement Function

  • Measured parameters: Voltage fluctuations = dc, dmax and d(t)200ms
    Flicker = Pst and Plt

  • Scaling for flicker: Logarithmic separation of 0.01-6,400 P.U. range into 1,024 divisions

  • Accuracy: Half-period rms value = ± (0.1% of reading + 0.1% of range)
    Pst, Plt = ± 5% (when Pst = 1)

  • Judgment function: Judges the pass/fail for all measured data items by comparison with the given limits

  • Printout: Interval-by-interval measured data, judgment result, CPF (cumulative probability function) graph and comprehensive judgment result.
